Ball Valves for Marine & Offshore Applications – Saltwater-Resistant Valves Built for Harsh Environments

When dealing with seawater, brine, oil, fuel, and high-pressure lines at sea, you need valves that can withstand corrosion, pressure surges, and extreme conditions. At Perfect Engineers, we manufacture and supply marine-grade Ball Valves specifically engineered for ships, offshore rigs, FPSOs, desalination plants, coastal refineries, and subsea installations.

Made from high-performance alloys like Super Duplex, Monel, Inconel, and Bronze, our marine ball valves ensure zero leakage, long operational life, and reliable shut-off even in the toughest offshore environments.

Table of Contents

What Are Marine Ball Valves?

Marine & Offshore Ball Valves are corrosion-resistant quarter-turn valves designed for:

  • Seawater and salt-laden environments
  • High vibration and pressure cycles
  • Offshore safety systems and confined installations
  • Compliance with maritime certifications (on request)

They’re essential in:

  • Seawater cooling systems
  • Ballast water pipelines
  • Fuel and bilge systems
  • Offshore production skids
  • FPSO transfer systems

Key Features of Our Marine Ball Valves

  1. Constructed from Super Duplex, Monel, Bronze, Inconel, or SS316L
  2. Pressure ratings: PN16 to PN160 / Class 150 to 1500
  3. Fire-safe, anti-static, and blowout-proof stem designs
  4. Compatible with hot/cold water, glycol, RO, soft water
  5. Available in 2-way, 3-way, full bore, trunnion-mounted types
  6. End connections: Flanged, SW, BW, BSP, NPT, RTJ
  7. Surface treated with marine-grade coatings (epoxy/ENP/phosphate)
  8. Compliant with API 607, ASTM, DNV, and NACE MR0175 standards

Technical Specifications

Parameter Specification
Size Range ½” to 12” (DN15 to DN300)
Body Material Super Duplex F55, Monel 400/K500, Inconel, Bronze, SS316L
Seat Options PTFE, Graphite, PEEK, Metal Seated
Pressure Rating Class 150 to 1500 / PN16 to PN160
Temperature Range -40°C to +250°C
End Connections Flanged (ANSI/DIN), RTJ, SW, BW, Threaded
Operation Manual / Pneumatic / Electric / Gear Operated
Certifications API 6D, API 607, DNV, CE, IBR, EN 3.1 MTC

Recommended Materials by Application

Media / Exposure Recommended Valve Material
Seawater / Brine Super Duplex / Monel / Bronze
Fuel Oil / Diesel SS316 / WCB with fire-safe design
Chlorinated Wastewater Alloy 20 / Inconel
Compressed Air / Gas SS316 / Inconel
Acidic Cleaning Systems PTFE-lined / Hastelloy

Contact Us for Pricing & OEM Support

Call

+91-9004860491

Website

www.perfectqrc.com

Applications in Marine & Offshore Systems

  1. Seawater intake and discharge systems
  2. Ballast water lines on ships and FPSOs
  3. Fuel oil and bilge management
  4. Cargo tank isolation and transfer valves
  5. Offshore platform gas & liquid skids
  6. Cooling systems for marine diesel engines
  7. Desalination and brine rejection pipelines
  8. Firewater isolation valves

Installation & Maintenance Tips

  • Use marine-grade bolts, gaskets, and supports to prevent galvanic corrosion
  • Apply cathodic protection or isolation kits where dissimilar metals meet
  • Always verify valve coating before installation in salt-exposed zones
  • Use gear-operated valves in confined or offshore deck areas
  • Perform scheduled flushing and greasing to maintain sealing integrity

FAQs

Yes—all valves used in fuel or oil lines are API 607 fire-safe certified.

Yes—DNV, CE, IBR, and other third-party approvals are available on request.

Absolutely—all valves are ISO 5211 actuator-ready and can be fitted with electric or pneumatic actuators.

Yes—we provide corrosion-proof, epoxy-coated or nickel-plated valves ideal for ballast and bilge water handling.
