When dealing with seawater, brine, oil, fuel, and high-pressure lines at sea, you need valves that can withstand corrosion, pressure surges, and extreme conditions. At Perfect Engineers, we manufacture and supply marine-grade Ball Valves specifically engineered for ships, offshore rigs, FPSOs, desalination plants, coastal refineries, and subsea installations.
Made from high-performance alloys like Super Duplex, Monel, Inconel, and Bronze, our marine ball valves ensure zero leakage, long operational life, and reliable shut-off even in the toughest offshore environments.
Marine & Offshore Ball Valves are corrosion-resistant quarter-turn valves designed for:
They’re essential in:
Parameter | Specification |
---|---|
Size Range | ½” to 12” (DN15 to DN300) |
Body Material | Super Duplex F55, Monel 400/K500, Inconel, Bronze, SS316L |
Seat Options | PTFE, Graphite, PEEK, Metal Seated |
Pressure Rating | Class 150 to 1500 / PN16 to PN160 |
Temperature Range | -40°C to +250°C |
End Connections | Flanged (ANSI/DIN), RTJ, SW, BW, Threaded |
Operation | Manual / Pneumatic / Electric / Gear Operated |
Certifications | API 6D, API 607, DNV, CE, IBR, EN 3.1 MTC |
Media / Exposure | Recommended Valve Material |
---|---|
Seawater / Brine | Super Duplex / Monel / Bronze |
Fuel Oil / Diesel | SS316 / WCB with fire-safe design |
Chlorinated Wastewater | Alloy 20 / Inconel |
Compressed Air / Gas | SS316 / Inconel |
Acidic Cleaning Systems | PTFE-lined / Hastelloy |
+91-9004860491
www.perfectqrc.com
SS316 may corrode over time in seawater. We recommend Super Duplex, Monel, or bronze valves for better pitting resistance.
Yes—all valves used in fuel or oil lines are API 607 fire-safe certified.
Yes—DNV, CE, IBR, and other third-party approvals are available on request.
Absolutely—all valves are ISO 5211 actuator-ready and can be fitted with electric or pneumatic actuators.
Yes—we provide corrosion-proof, epoxy-coated or nickel-plated valves ideal for ballast and bilge water handling.
